PM Sport Screens Indoor & Outdoor

PM Sport LED Screens Indoor & Outdoor



SMD


Product type PM8.9 PM10
Pixel pitch(mm)  8.928 10
Pixel configuration SMD3535 SMD3535
Module size(mm) 500x125 240x240
cabinet size(WxHxD mm) 1000x875x75 960x960x75
Pixel Density(Pixels/m2) 12.544 10.000
Brightness(cd/m2) >5500 >5500
cabinet material Extruded Aluminium Extruded Aluminium
cabinet weight(kg) ~39kg ~30kg
Input Power Frequency >1000 Hz >1920 Hz
Input vollage(Nominal V) 220V(110. 110-220) 220V(110. 110-220)

DIP

Product type FG10 FG16
Pixel pitch(mm)  10 16
Pixel configuration 1R1G1B DIP 346 1R1G1B DIP 346
Module size(mm) 320x320 256x128
cabinet size(WxHxD mm) 1280x960x150 1280x896x200
Pixel Density(Pixels/m2) 10.000 3906
Brightness(cd/m2) >6000 >6000
cabinet material Extruded Aluminium Extruded Aluminium
cabinet weight(kg) ~65 ~75
Input Power Frequency >1000 Hz >1000 Hz
Input vollage(Nominal V) 220V(110. 110-220) 220V(110. 110-220)
